Carton stitcher machine is an indispensable equipment in the carton packaging industry, and special attention should be paid to the maintenance of the carton stitcher:

Before using the newly purchased Carton stitcher machine, be sure to read the equipment instruction manual carefully.

(Understand the basic structure, performance and use methods of the equipment to avoid blindness in operation and use)

1. When nailing the box, adjust the position of the main baffle, the left and right baffles, and the position of the upper and lower nail heads according to the flap of the carton.

When adjusting, it should be noted that the left and right baffles cannot be clamped too tightly, and the cardboard should be easily inserted and pulled out.

2. When the mechanical adjustment is completed, you can touch the screen to set the computer:

a series of settings such as carton height, carton nail number, carton spacing, whether to order reinforcement nails, single-piece, double-piece selection, etc. .

3. While paying attention to the correct use of the nail box machine, we must pay attention to the correct maintenance and maintenance of the machine, which is the key link to improve production efficiency and nail box quality and must not be ignored.

Therefore, it is required to lubricate the head and punch on the machine once a day; the fixed shaft of the head and the fixed shaft of the left and right baffles should also be lubricated and cleaned with oil at any time.
The upper and lower nail head drive shafts, bolt groove shafts, and drive screws should also be well lubricated.
The lowering head is easy to accumulate in the punch due to the falling off of part of the electroplating scraps when the flat wire is fed, and should be cleaned and cleaned frequently.
After every month, disassemble the head for cleaning and refueling.
The three gears of the left and right baffles of the paper feed belt bolt groove shaft should be filled with butter once a month.

4. Clutches and brakes should prevent oil and water from entering and infiltrating

Servo motors should be kept clean to avoid dust accumulation;
Clean the cooling dust filter of the servo motor driver frequently;
The electrical control box should be kept clean to prevent short circuit failure caused by dust accumulation;
The inner and outer feeding reels should be lubricated with butter to keep them reliable and flexible;
The gears and chains of the power transmission are required to be lubricated with grease once a month to prevent the wear of mechanical parts.

Lukes Machinery has obtained the production patent of the automatic Carton stitcher machine, and its quality service is trustworthy! If you are interested in this product, please contact me.
